100W Aluminum material industrial LED UFO High Bay Light high lumen waterproof IP65 for warehouse use
Model No.:WT-UFO-J-100W
Rated Power(W):100W
Input Voltage(V):AC85-265V
LED Type:SMD3030
Frequency Range(HZ)50-60Hz
Color Temperature(K)2700-6500K
Power Fcator(PF):>0.9
Material:Aluminum
Working temperature:-20-+45
Warranty:2-5 Years
Packing:1PCS/CTN
CRI>80.
High lumen SMD3030 LED chip.
Luminous efficieny>100lm/W,long lifespan.
Branded driver used AC85-285V or AC180-528V input, 2-5 years guarantee.
PC lens or glass lens optional.
Lens angle:60/90/120 degree.
Integrated die-casting aluminum housing,powder painting agaist harsh environments.
Products' Advantages
>>> Die-casting aluminum heat sink
>>> Higher lumen efficiency 100-120lm/W
>>> 2-5 years warranty, IP65
>>> Reflector free and smaller packing size to save shipping cost
>>> Green product, compliant with ROHS and CE.
100W Aluminum material LED UFO High Bay Light front view
100W Aluminum material LED UFO High Bay Light back side
LED UFO High Bay Light Packing
1)Packing:1PCS/CTN
2)Packing Size:33*33*17cm
3)Net Weight:2.5KG/PCS
4)Gross Weight:3.0KG/PCS
| Item NO. | Watt | LED Data | CRI | CCT | Lumens | LED Driver Data | Housing color | Beam angle | Product size | Net weight | Gross weight | PCS/CTN | Outer carton size |
| K | LM/W | ° | mm | KG | KG | PCS | CM | ||||||
| HLY-UFO-J-SMD60W | 60W | Sanan chip 3030LED;1W 3.0-3.2V/6.0-6.2V ;lumen120-130LM | 70/80 | 3000K/6500K | 100-110LM/W | Input Voltage AC85-265V;Output Voltage 30-36V;Waterproof IP65;75 pcs LED | black | 60/90° | 250*162mm | 2.4KG | 2.8KG | 1 | 33*33*17cm |
| HLY-UFO-J-SMD100W | 100W | Input Voltage 85-265V;Output Voltage 30-36V;Waterproof IP65;100 pcs LED | 60/90° | 250*162mm | 2.5KG | 3KG | 1 | 33*33*17cm | |||||
| HLY-UFO-J-SMD150W | 150W | Input Voltage 85-265V;Output Voltage 30-36V;Waterproof IP65; 144pcs LED | 60/90° | 316*162mm | 3.2KG | 3.8KG | 1 | 39*39*17cm | |||||
| HLY-UFO-J-SMD200W | 200W | Input Voltage 85-265V;Output Voltage 30-36V;Waterproof IP65; 204pcs LED | 60/90° | 350*172mm | 4.3KG | 4.9KG | 1 | 43*43*17cm | |||||
| HLY-UFO-J-SMD240W | 240W | Input Voltage 85-265V;Output Voltage30-36V;Waterproof IP65; 272pcs LED | 60/90° | 380*173mm | 5.3KG | 5.9KG | 1 | 46*46*19cm |
Where can be LED UFO High Bay Light used?
The UFO led high bay light widely apply to industrial, workshop, warehouse and other field.
| Item NO. | Watt(W) | Lumen(LM) | CRI(Ra) | Size(MM) |
| WT-UFO-J-60W | 60W | 100-130LM/W | ＞80 | Φ250*162mm |
| WT-UFO-J-100W | 100W | Φ250*162mm | ||
| WT-UFO-J-150W | 150W | Φ316*162mm | ||
| WT-UFO-J-200W | 200W | Φ350*172mm | ||
| WT-UFO-J-240W | 240W | Φ380*173mm |
|
|
